40pins Laptop Screen 3840×2160 DPN 0FNVDR 4k Ultra Hd Lcd Monitor LQ156D1JX41
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Sharp |
| Model Number: | LQ156D1JX41 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 5 |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Brand: | Sharp | Model: | LQ156D1JX41 |
|---|---|---|---|
| Size: | 15.6 | Panel Type: | Oxide TFT-LCD, Module |
| Resolution: | 3840(RGB)×2160, UHD, 283PPI | Pixel Layout: | RGB Vertical Stripe |
| Display Area: | 344.218(W)×193.622(H) Mm | Appearance Dimensions: | 348.12(W)×214.12(H)×3.7(D) Mm |
| Support Colors: | 16.7M , 100% SRGB | Surface Treatment Mirror: | Mirror Face (Haze 0%)，Hard Coating |
| Brightness: | 400 Cd/m² (Typ.) | Contrast Ratio: | 1500 : 1 (Typ.) [Transmission] |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Working Mode: | IPS，Constant Black Display, Transmissive |
| Refresh Rate: | 60Hz | Touch Function: | No Touch, |
| Appearance Style: | Thin Screen (PCBA Flat, Thickness ≤ 3.2mm) | Panel Application: | Notebook Computer |
| Voltage: | 3.3V (Typ.) | Maximum Rating: | Storage Temperature:- 20~60 ° C Operating Temperature: 0 ~ 50 °C |
| Interface Type: | 40 Pins EDP (4 Lanes) , EDP1.4a , 4.32G/lane , Terminal | ||
| Highlight: | 40pins Laptop Screen,3840×2160 4k ultra hd lcd monitor,LQ156D1JX41 |
||
Product Description
LQ156D1JX41 40pins 3840×2160 DPN 0FNVDR UHD 4K NEW
Sharp's LQ156D1JX41 (product code: SHP148D is a 15.6-inch LCD module product using Oxide TFT-LCD technology. It is equipped with WLED backlight, LED driver backlight driver, and touch free. To summarize its typical features: sRGB, White LED backlight, including LED driver, inverted terminal, mirror surface, eDP1.4a. Its working temperature is 0~50 ° C, and its storage temperature is -25~60 ° C. This model is suitable for use in laptops. And the parameters were finally updated on November 7th, 2024. According to the product specification document LD-D5117Z01A released by Sharp on December 25, 2017, the LQ156D1JX41 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and RGB vertical stripe arrangement of pixels. The pixel density calculated by the screen library is 283 PPI. Its display area size is 344.218 × 193.622 (width × height) mm, and its appearance size is 348.12 (width) × 214.12 (height) × 3.7 (thickness) mm. The surface treatment is mirror (Haze 0%), Hard coating, and the net weight of the product is 270/290g (Typ./Max.). The appearance style is thin screen (PCBA flat, thickness ≤ 3.2mm). In terms of backlight, this product adopts a WLED side entry light source with a lifespan of 15K hours and includes an LED driver. LQ156D1JX41 adopts eDP (4 Lanes) signal interface, with a total of 40 pins, connected by terminals, and a screen driving voltage of 3.3V (Typ.). Its typical vertical refresh rate Fv is 60Hz.
Packing & Shipping
Trading Process
FAQ
1.Can I purchase the products in 1 piece?
Yes,you can,but we do not recommend,because the shipping cost is very high.
2.What payment method can I use?
T/T is the best,we aslo accpet Paypal
3.When is the shipment?
Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment,
and will use third parties delivery services or delivered as clients request.
4.How long is the warranty period?
12 Months
5.How to do if there is a product quality problem?
Please contact the relevant sales as soon as possible.
